TPSJ-101
Model: 5642-CO
Reward Points: 38
Availability: 30 - 60 Days (CALL)
Reward Points: 38
Availability: 30 - 60 Days (CALL)
Price: $42.00
Price in reward points: 1550
Price in reward points: 1550
Qty:
- OR -
Add to Wish List
Add to Compare
Add to Compare
- Mates with U-92A/U, TJ-101, TJ-120, U-94A/U
- Cable mounted telephone plug
- DPDT Slide Switch
- MJ-101 Jack Section
- Ruggedized Commercial / Military
| General Description | |
| Color(s) | Black |
| # of Pieces | X |
| Length | 2.875 in |
| Diameter | .500 in |
| Compliance | ISO 9001:2008 CERTIFIED |
| MIL Spec | MIL-C-9177 |
| Connector Specifications | |
| Conductors | 4 |
| Contact Diameter | .281 in |
| Contact Length | .761 in |
| Shell Material | Plastic |
| Solder Contact Terminals | Pre-tinned over Nickel Plating |
| Contact Resistance | ≤ .02 O |
| Insulation Resistance | ≥ 1,000 mO |
| Dielectric Withstanding Voltage (RMS) | ≥ 500 V |
| Insertion Force Maximum | 13 lb |
| Withdrawal Force | 6 to 10 lb |
| Mates with | U-92A/U, TJ-101, TJ-120, U-94A/U |
