U-92A/U (TJ-102)
Model: 5501-CO
Reward Points: 8
Availability: In Stock
Reward Points: 8
Availability: In Stock
Price: $32.50
Price in reward points: 325
Price in reward points: 325
Qty:
- OR -
Add to Wish List
Add to Compare
Add to Compare
| General Description | |
| Color(s) | Black |
| # of Pieces | 3 |
| Length | 2.312 in |
| Width | .828 in |
| Height | .828 in |
| Compliance | ISO 9001:2008 CERTIFIED |
| MIL Spec | MIL-C-9177 |
| Connector Specifications | |
| Conductors | 4 |
| Contact Diameter | .285 in |
| Shell Material | Plastic |
| Contact Material | Nickel Plated Beryllium Copper |
| Solder Contact Terminals | Pre-tinned over Nickel Plating |
| Contact Resistance | ≤ .02 O |
| Insulation Resistance | ≥ 1,000 mO |
| Dielectric Withstanding Voltage (RMS) | ≥ 500 V |
| Insertion Force Maximum | 13 lb |
| Withdrawal Force | 6 to 10 lb |
| Mates with | TP-120, U-174/U, 93A/U, TPSJ-101 |
| Known Part Numbers | |
| Acousticom | 5521-COM |
| MIL P/N | U-92A/U, M9177/3-1 |
| Nexus | TJ-102 |
| NSN | 5935-00-665-5125 |
